Brake Disc for Contractor and Heavy Duty Radial Arm Saws

Frequently Bought Together

Brake Disc for Contractor and Heavy Duty Radial Arm Saws + Brake Module for Radial Arm Saw + Brake Coil Assembly for Radial Arm Saws + Fan and Liner Assembly for Contractor Duty or Heavy Duty Radial Arm Saw
Price for all: $250.43

Brake Disc for Contractor and Heavy Duty Radial Arm Saws

$21.93

Features

The Brake Disc for Contractor and Heavy Duty Radial Arm Saws ensures reliable stopping power. This two-sided, reversible disc fits Original Saw Contractor Duty (Type 4+) and Heavy Duty models, plus certain DeWalt 3500 motors. Flip when worn; replace if braking time increases.

Select Options

In stock

Description

Brake Disc for Contractor and Heavy Duty Radial Arm Saws

Built to Restore Reliable Stopping

This replacement brake disc is a core part of your saw’s braking system. During shutdown, it applies friction against the Fan and Liner Assembly to bring the motor to a controlled stop—critical for safety and cut accuracy.

Compatibility

Note: Not designed for earlier Contractor Duty Types 1–3.

Two-Sided, Reversible Design

The Brake Disc for Contractor and Heavy Duty Radial Arm Saws is double-sided. If you notice glazing, grooves, or longer stopping times, remove and flip the disc to use the fresh side. Replace the disc once the friction liner has worn through the surface or if braking time continues to increase.

When to Inspect or Replace

  • Increased motor stopping time
  • Visible wear, glazing, or scoring on the disc
  • Friction liner contact worn through the disc
  • Persistent braking issues after installing a new brake coil

Troubleshooting & Related Components

If braking performance doesn’t improve after installing a new disc, inspect or replace these related parts:

Step-by-Step Repair Video

Watch how to replace a brake disc in your radial arm saw motor. This tutorial outlines the step-by-step process of removing and installing the brake disc, while also covering related components such as the brake module, fan and liner assembly, brake coil assembly, and tie rod kits to restore proper braking performance.

This video demonstrates:

  • Removing the brake coil
  • Relacing the brake disc
  • Replacing tie rods
  • Installing the fan and liner assembly
  • Reassembling the motor for reliable operation

For more helpful resources, subscribe to our YouTube channel.

Specifications

Additional information

Weight 1 lbs
Dimensions 4 × 4 × 4 in

Ordering and Shipping Information for the Brake Disc for Contractor and Heavy Duty Radial Arm Saws

How to Order

  • Online: Place your order directly on our website.
  • Phone: Call Customer Service at (800) 733-4063.
  • Email: Contact us at customerservice@originalsaw.com.

Shipping and Delivery

  • This part ships via UPS for reliable delivery.
  • Typical lead time is 2-3 days from order placement. Shipping times may vary based on destination and carrier availability.
  • Customers will receive a tracking number once the order has shipped.
  • Shipping costs are calculated at checkout and are non-refundable.

Questions and Assistance

For ordering and shipping questions, contact our Customer Service team at (800) 733-4063 or customerservice@originalsaw.com.
